The CASE CX90 Tractor, part of the CX Series, was produced in the late 1990s to early 2000s. The CX90 is a versatile machine designed for agricultural tasks, renowned for its durability and adaptability. With an 84-horsepower Perkins turbocharged diesel engine, it efficiently tackles a wide range of jobs, making it ideal for small to mid-sized farms as well as large-scale operations. Also, the red design of the vehicle’s body makes it particularly eye-catching when working in the field.
Although the CX90 is no longer in production, it remains popular in the used tractor market. Thanks to its reliability and ease of maintenance, its classic appeal makes it a favorite among farmers who prefer straightforward, mechanical tractors without complex electronics. Knowing its specifications and key features is crucial if you’re interested in machinery and looking to buy used equipment. Now, let’s take a deeper look at the machinery.

Key Advantages of the Tractor
- Versatility: The CX90 is designed to handle various agricultural tasks, from plowing and planting to hauling and mowing. It offers multiple transmission options, including an 8×8 synchro-shuttle, 16×8 powershift, and 24×12 powershift with creeper, allowing operators to choose the best configuration for their needs. This adaptability makes it an invaluable asset for diverse farming operations.
- Hydraulic System: Equipped with an advanced open center hydraulic system, the CX90 ensures efficient operation of various hydraulic implements. The system’s high fluid flow rate of 15.7 gallons per minute and a total flow of 24.2 gallons per minute enhance productivity and performance in demanding conditions. The hydraulic capacity varies between 34.4 liters for 2WD and 37.1 liters for 4WD models.
- Power and Efficiency: Powered by a robust Perkins 1004.40T 4-cylinder turbocharged diesel engine, the CX90 delivers 84 horsepower. This power, combined with efficient fuel consumption, ensures that the tractor can handle heavy workloads while maintaining cost-effectiveness. The engine’s displacement is 243.5 cubic inches, providing ample torque and reliability.
- Operator Comfort and Safety: The CX90 features hydrostatic power steering and differential hydraulic wet disc brakes, providing excellent maneuverability and safety. The optional cab with air conditioning and ergonomic controls enhances operator comfort, reducing fatigue during long hours of operation. The cab also includes a two-post ROPS with a flat platform for added safety.
- Durability and Reliability: Built with high-quality materials and engineered for longevity, the CX90 is known for its durability and low maintenance requirements. The tractor’s design includes easy access to service points, making routine maintenance straightforward. This reliability ensures that the tractor remains a dependable workhorse for years to come, even when purchased used.
CASE CX90 Tractor Specs
Power
| Engine (gross) | 90hp |
|---|---|
| Engine (net) | 84hp |
| PTO (claimed) | 74hp |
| Drawbar (tested) | 69.2hp |
| PTO (tested) | 79.7hp |
Capacity
| Fuel | 42 gal |
|---|---|
| Hydraulic system | 9.1gal (2WD) |
| 9.8gal(4WD) |
Dimensions & Tires
| Wheelbase | 92.3 inches (2WD) |
|---|---|
| 93.7 inches (4WD) | |
| Weight | 7396 to 8466 pounds |
| Front tire | 7.50-16 |
| Rear tire | 16.9-30 |
Mechanical
| Drive | 4×2 2WD |
|---|---|
| 4×4 MFWD (optional) | |
| Differential lock | electro-hydraulic |
| Steering | hydrostatic power |
| Two-post ROPS with a flat platform | Optional cab with air-conditioning |
Tractor Hitch
| Rear Type | II/I |
|---|---|
| Control | electronic upper link |
| Rear lift | 3,665 lbs |
| 5,097 lbs (optional) |
Power Take-off (PTO)
| Rear PTO | independent |
|---|---|
| Clutch | hydraulic wet disc |
| Rear RPM | 540 |
| 540/100 (optional dual shaft) |
Hydraulics
| Type | open center |
|---|---|
| Capacity | 9.1 gal (2WD) |
| 9.8 gal (4WD) | |
| Pressure | 2500 psi |
| Valves | 0 to 3 |
| Pump flow | 15.7 gpm |
| Total flow | 24.2 gpm (total) |
| 15.7 gpm (main pump) | |
| 8.5 gpm (lube pump) |
Why is CASE CX90 Easy to Maintain?
The CASE CX90 Tractor is considered easy to maintain for several reasons, which contribute to its long-lasting popularity. In a word, the combination of a mechanical focus, readily available parts, and accessible design makes the machinery a go-to machine for those who want minimal fuss when it comes to upkeep.
Simplicity of Design
Unlike modern tractors with complex electronic systems, the CX90 relies more on mechanical components. So it is easier for farmers and operators to perform routine maintenance and repairs without the need for specialized tools or knowledge.
Abundant Aftermarket Parts
Though CX90 is no longer in production, there is still a wide range of aftermarket parts readily available. No matter whether you want an engine component, a hydraulic system part, or any other common replacement part, you can easily find affordable parts to repair the machinery.
Accessible Engine Compartment
A major feature of the CX90 is the open-wide hood. It gives easy access to critical components like the engine, filters, and belts. This design makes regular maintenance tasks like checking fluids, changing filters, or replacing belts straightforward.
CASE CX90 Tractor Parts Lookup
Conclusion
In conclusion, the tractor remains a considerable choice for those who want to buy a reliable and durable used tractor. Its straightforward design, ease of maintenance, and availability of affordable aftermarket parts make it a dependable workhorse for various agricultural tasks. If you already own a CASE CX90 or are planning to buy one, make sure to keep it in top shape with quality replacement parts. At FridayParts, we offer a wide selection of aftermarket CASE parts specifically designed for the CASE CX90, including hydraulic components, engine parts, filters, and more. Visit our website today to explore our inventory and keep your CX90 running smoothly for years to come!
